Wedge steel DIN 6880 16x16 - 1m

Product detailed description

The wedge steel according to DIN 6880 with dimensions of 16x16 mm and a length of 1 meter is intended for the production of machine keys or wedges. This component is made of steel grade C45K, which is known for its high strength and ability to reliably transmit torque. C45K steel is a carbon steel with good machinability, which allows it to be precisely machined to suit the requirements of a specific application.

The wedge steel has precise dimensions of 16 mm in width and 16 mm in height, which corresponds to the h9 tolerance according to DIN 6880. This standard defines precise dimensions and tolerances for wedge steels, ensuring their compatibility and reliability in mechanical connections. The length of 1000 mm allows it to be used flexibly in various applications, and can be adjusted to the required length as needed.

The surface finish of this wedge steel is without additional treatment, which means that the surface is not galvanized or otherwise treated. This allows it to be further processed or modified according to the specific needs of the project. The wedge steel is an ideal solution for mechanical connections where it is necessary to ensure a solid and reliable transmission of torque between the shaft and the hub.
