Timing belt 680 8M 20 optibelt Omega HP
Code: 252908
Product detailed description
Timing belt 8MHP 680 - 20 mm is a high-performance chloroprene belt. The manufacturer's type designation optibelt is 680 8MHP 20. The 8MHP profile defines a tooth pitch of 8 mm and a height of 5.4 mm. The timing belt is 680 mm long and has a width of 20 mm. The width can be adjusted as desired. The exact number of teeth is 85 pcs, which will help us determine the length. The trade name OMEGA HP. is a supplier of special belts of the highest quality for all types of operation. Thousands of pieces in stock and fast shipping guarantee your satisfaction.Additional parameters
| Category: | Belts > flat gear > 8M (8x6) > width 20 mm |
|---|---|
| Weight: | 0.08 kg |
| EAN: | 4014486189186 |
| Calculation length Lw, Lp, mm: | 680 |
| Height H (mm): | 5,4 |
| Height H1 (mm): | 3,2 |
| Manufacturer's brand: | Optibelt |
| Number of teeth (splines): | 85 |
| Product: | OMEGA HP |
| Profile: | 8M |
| Spacing t (mm): | 8 |
| Width B (mm): | 20 |
| Číslo výrobce: | 1627537 |
| Značení: | 680 8MHP 20 |
| Řada: | 680-SLV2-8M-20 |
| Typ: | Rozvodový řemen ozubený |
