    Home / Belts / flat gear / 5M (5x3.8) / width 15 mm / Timing belt 450 5M 15 Gates Powergrip HTD

    Timing belt 450 5M 15 Gates Powergrip HTD

    Code: 548308
    Not rated
    Timing belt 450 5M 15 Gates Powergrip HTD
    12,47 € / pcs 15,09 € incl. VAT
    In stock (40 pcs)
    Delivery to:
    06/08/2025
    Delivery offer
    Standard quality / number of teeth 90 / length 450mm / width 15mm / profile 5M / marking POWERGRIP HTD / manufacturer Gates

    Detailed information

    Delivery throughout the EU

    Product detailed description

    Thanks to optimized load distribution, the involute tooth profile of the HTD® belt guarantees high power transmission in low-speed, high-torque applications. PowerGrip® HTD® belts 3M and 5M are suitable for home use, office machines, power tools and for use in the process and chemical industries.
    Alternative markings
      / Optibelt Omega HTD / Contitech Synchrobelt HTD / Megadyne RPP5M-450-15 / SKF HiTD / PIX X treme HTD / Goodyear Hi-Performance Pd / Bando Synchro-Link
    The three-digit code on the back of the belt indicates the belt length, pitch and width.

    Construction
      _x000 improves stress distribution and allows higher total loads to be used.
    • Precision-molded elastomeric teeth with precise spacing ensure correct positioning in the pulley groove.
    • Durable elastomeric backing protects against contamination of the belt side.
    • The teeth protect hard nylon surface.
    • Glass fiber tension cords.
    • Compact design.
    _x000 Advantages
    • PowerGrip® HTD® 3M and 5M belts are designed for speeds up to 20,000 rpm and up to 10 kW. • The optimized tooth shape allows for high load transmission even with small spacings.
    • Due to small manufacturing tolerances, the distances between the fixed axes are predictable. In addition, the high degree of flexibility allows the use of very small pulleys (outer diameter 8.79 mm).
    • Peripheral speed up to 80 m/s.
    • Efficiency up to 99%.
      • <0>Compact design. resistance to tooth skipping.
    • Long service life and maintenance-free.

    Additional parameters

    Category: Belts > flat gear > 5M (5x3.8) > width 15 mm
    Weight: 0.025 kg
    EAN: 5412571279047
    Calculation length Lw, Lp, mm: 450
    Cord type: GL
    Country of origin: GB
    Height H (mm): 3,8
    Manufacturer's brand: Gates
    Material: CR
    Number of teeth (splines): 90
    Product: POWERGRIP HTD
    Profile: 5M
    Spacing t (mm): 5
    Width B (mm): 15
    Číslo výrobce: 9293-32045
    Značení: HTD 450 5M 15
    Řada: 450-RPP5-15
    Typ: ozubený
    Timing belt 450 5M 15 optibelt Omega
    9,92 € –18 %
    Timing belt 450 5M 15 optibelt Omega
    In stock (3120 pcs)
    9,82 € incl. VAT
    8,12 €

    Standard quality / number of teeth 90 / length 450mm / width 15mm / profile 5M / marking OMEGA / manufacturer Optibelt

    Code: 251783
    Timing belt 450 5M 15 optibelt Omega HP
    16,36 € –29 %
    Timing belt 450 5M 15 optibelt Omega HP
    In stock (1659 pcs)
    14,05 € incl. VAT
    11,61 €

    Top quality / number of teeth 90 / length 450mm / width 15mm / profile 5M / OMEGA marking / manufacturer Optibelt

    Code: 252787
