SKF P 80 stationary sheet metal bearing housing

Product detailed description

The SKF P 80 sheet metal pillow block housing is designed to accommodate bearings with an external spherical surface. This component is made of sheet steel, which ensures its durability and reliability in light to medium-duty applications. The housing is compact and its design allows for effective mounting of the bearing, while providing stable support and minimizing vibrations.

The dimensions of the bearing housing are precisely defined: diameter D is 80 mm, length L is 148 mm, width B is 86 mm, and height H is 86 mm. Other important dimensions include hole spacing J of 120 mm, pitch N of 14 mm, width A1 of 29 mm, height H1 of 43.5 mm, and height H2 of 5 mm. These parameters are critical for correct placement and assembly within mechanical systems.

The housing is equipped with a thread G with a diameter of 12 mm, which allows for easy and firm mounting. The total weight of the component is 0.31 kg, which contributes to its easy handling and installation. The surface finish is in silver color, which provides protection against corrosion and aesthetically fits into various industrial environments.

SKF P 80 is a split bearing housing, which means that it is designed to allow easy maintenance and replacement of the bearings without having to dismantle the entire system. The mounting can be done from the top or bottom, which provides flexibility in mounting in various applications. This product is ideal for use in various industries where reliable support of spherical surface bearings is required.
