SKF NU 1005 roller bearing
Code: 331558
Product detailed description
SKF NU 1005 - single row separable radial roller bearing with a pressed window steel cage guided by rollers with normal radial internal clearance. The bearing can operate at temperatures up to +150°C.The outer ring of the bearing has two guide flanges and the inner one is without flanges, which allows axial displacement of the shaft relative to the housing in both directions. The rollers are guided by flanges.
The bearing can be divided into an outer ring with a cage with rollers and an inner ring for easier assembly.
Additional parameters
| Category: | Bearings > roller > single row > Well 10.. > NU 1005 |
|---|---|
| Weight: | 0.083 kg |
| EAN: | 7316577012876 |
| Cage: | steel |
| Clearance: | normal |
| Diameter D (mm): | 25, 47 |
| Hole profile: | cylindrical |
| Manufacturer's brand: | SKF |
| Material: | steel |
| Maximum temperature °C: | +150 |
| Minimum temperature °C: | -30 |
| Seal: | without gaskets |
| The shape of the outer ring: | without groove / lubrication hole |
| Width B (mm): | 12 |
| Značení: | NU 1005 |
| Typ: | válečkové ložisko |
