SKF 624-2Z deep groove ball bearing
Code: 310478
Product detailed description
SKF bearing 624 2Z - non-separable single row radial ball bearing with a steel cage guided by balls with non-contact sheet metal seals on both sides and normal radial clearance. The cover plates of the 624-2Z bearing are pressed into grooves in the outer ring. The 624-2Z bearing is designed for mounting with a rotating inner ring and is filled with high-quality lubricant with a temperature range from -40°C to +100°C for the entire service life of the bearing.Additional parameters
| Category: | Bearings > ball > miniature d=0.6 to 9mm > d = 4 mm > 624 (D=13 B=5) |
|---|---|
| Weight: | 0.003 kg |
| EAN: | 7316577075031 |
| Cage: | steel |
| Clearance: | normal |
| Diameter D (mm): | 4, 13 |
| Hole profile: | cylindrical |
| Manufacturer's brand: | SKF |
| Material: | steel |
| Maximum temperature °C: | +120 |
| Minimum temperature °C: | -20 |
| Seal: | double-sided cover, sheet metal |
| Width B (mm): | 5 |
| Značení: | 624-2Z |
| Typ: | kuličkové ložisko |
