SKF 6203-2Z/C4 deep groove ball bearing
Code: 312434
Product detailed description
SKF bearing 6203 2Z C4 - non-separable single-row radial ball bearing with a steel cage guided by balls with a non-contacting sheet metal seal on both sides and with a higher radial clearance than C3. The cover plates of the 6203-2Z C4 bearing are pressed into the grooves of the outer ring and fit against the smooth inner ring. The 6203 2Z C4 bearing is designed for mounting with a rotating inner ring and is filled with high-quality lubricant with a temperature range from -40°C to +100°C for the entire service life of the bearing. If the outer ring rotates, lubricant may leak at higher speeds.Additional parameters
| Category: | Bearings > ball > single row 62xx > 6203 > sheet metal covers |
|---|---|
| Weight: | 0.066 kg |
| EAN: | 7316570819786 |
| Cage: | steel |
| Clearance: | C4 - strongly enlarged |
| Diameter D (mm): | 17, 40 |
| Hole profile: | cylindrical |
| Manufacturer's brand: | SKF |
| Material: | steel |
| Maximum temperature °C: | +120 |
| Minimum temperature °C: | -20 |
| Seal: | double-sided cover, sheet metal |
| The shape of the outer ring: | without flange / groove |
| Width B (mm): | 12 |
| Značení: | 6203-2Z/C4 |
| Typ: | kuličkové ložisko |
