SKF 6005-2Z/VA208 deep groove ball bearing
Code: 618526Product detailed description
SKF 6005-2Z/VA208 ball bearing - Single row deep groove ball bearings for high temperature applications with double shields are designed for severe operating conditions, with some variants capable of operating at temperatures up to 350 °C. They have a larger radial internal clearance and use graphite-based lubricants that allow operation at high temperatures. They are lubricated for the entire life of the bearing and the entire surface of the bearings and shields is treated with manganese phosphate, which increases the adhesion of the lubricant to the metal and improves their running-in properties. Like ball bearings in general, they are extremely versatile, can withstand radial and axial loads in both directions and are easy to mount. They are optimized for operation at high temperatures - up to 350 °C (660 °F). Easy replacement with grease-lubricated bearings of the corresponding ISO dimensions. Increased reliability, reduced complexity and reduced environmental impact. Integrated seal extends bearing life.Additional parameters
Category: | Bearings > ball > single row 60xx > 6005 > for low and high temperatures |
---|---|
Weight: | 0.077 kg |
EAN: | 7316570511383 |
Cage: | graphite |
Clearance: | C5 - very strongly enlarged |
Diameter D (mm): | 25, 47 |
Hole profile: | cylindrical |
Manufacturer's brand: | SKF |
Material: | phosphated steel |
Maximum temperature °C: | +350 |
Minimum temperature °C: | -150 |
Seal: | double-sided cover, sheet metal |
The shape of the outer ring: | without flange / groove |
Width B (mm): | 12 |
Značení: | 6005-2Z/VA208 |
Typ: | kuličkové ložisko |
