SKF 3316 A angular contact ball bearing
Code: 328108
Product detailed description
SKF 3316 A - non-separable double row angular contact ball bearing with optimized internal design without filler grooves, pressed steel open cage guided by two rows of balls and with normal axial clearance. The bearing has a contact angle of 3. A pair of single row angular contact ball bearings in the \O\ configuration, i.e. back to back, and can carry radial and bidirectional axial loads."Additional parameters
| Category: | Bearings > ball bearing with diagonal contact > 33.. (53..) double row > 3316 |
|---|---|
| Weight: | 6.269 kg |
| EAN: | 7316570812350 |
| Angle ( ° ): | 30° |
| Cage: | steel |
| Clearance: | normal |
| Diameter D (mm): | 80, 170 |
| Hole profile: | cylindrical |
| Manufacturer's brand: | SKF |
| Material: | steel |
| Maximum temperature °C: | +150 |
| Minimum temperature °C: | -20 |
| Seal: | without gaskets |
| The shape of the outer ring: | without flange / groove |
| Width B (mm): | 68,3 |
| Značení: | 3316 A |
| Typ: | kuličkové ložisko s kosoúhlým stykem |
