Shaft retaining ring DIN 471 - 40 mm stainless steel A1

Product detailed description

The DIN 471 shaft retaining ring, also known as a circlip, is designed to axially secure components on a shaft. This particular model has a diameter of 40 mm and is made of A1 grade stainless steel, which guarantees high corrosion resistance and long service life even in harsh operating conditions. The material 1.4122, from which the ring is made, is a martensitic stainless steel, which provides good strength and wear resistance.

Retaining rings are essential for securing bearings, gears and other rotating assemblies where axial movement of components needs to be prevented. This ring is designed to be placed in a groove on the shaft, providing a firm and reliable lock. The ring dimensions are 40 mm in diameter and 1.75 mm thick, which is a standard size for this type of application.

The use of A1 grade stainless steel is ideal for applications where the ring is exposed to moisture or chemicals, as the material is resistant to corrosion. This property is particularly important in industrial applications where components are often exposed to aggressive environments.

The DIN 471 shaft retaining ring is an essential element in mechanical engineering and its correct installation is crucial to ensure the reliable and safe operation of mechanical systems. Its use is wide, from the automotive industry to the production of machinery and equipment, where the securing of rotating components is required.
