Retaining ring for hole DIN 472 - 85 mm

Product detailed description

The DIN 472 circlip with a diameter of 85 mm is designed to secure parts inside a hole. This type of ring, also known as an internal circlip, is designed for axial securing of bearings and shaft assemblies. It is made of spring steel, which guarantees its high elasticity and resistance to mechanical stress. The ring has dimensions of 85 x 3 mm, while the 3 mm thickness provides sufficient strength for reliable fastening in applications with high demands on stability and safety.

Circlips according to DIN 472 are standardly used in mechanical engineering and the automotive industry, where they serve to secure components inside holes, preventing their axial movement. This particular model is uncoated, which can be advantageous in applications where additional corrosion protection is not required or where a clean steel finish is required for specific technical requirements.

The ring is part of a group of fasteners, namely retaining rings, and is often referred to as a circlip or safety ring. Its installation requires precise seating in a groove in the hole, which ensures its function as a reliable locking element.
