Multi-ribbed belt 5 PK 850 (335-K) optibelt RBK
Code: 258567
Product detailed description
Multi-V-belt 5 PK 850 from the manufacturer optibelt, type RBK. Also known as a grooved belt, toothed belt or ribbed belt. It meets high demands on power transmission and high speeds. The inch designation is 335-K, where \K\ stands for the profile - equivalent to \PK\ and 335 is the inch length of the belt. In this case 33.5 inches = 850 mm. What is not indicated on the belt is the number of ribs. Since the belt is cut from the sleeve, the number of ribs (wedges) is necessary. 5 ribs. The belt has a very long service life and is suitable for small pulley diameters."""Additional parameters
| Category: | Belts > flat ribbed > PK 3.56 mm > 5 PK |
|---|---|
| Weight: | 0.077 kg |
| EAN: | 4014486350128 |
| Calculation length Lw, Lp, mm: | 850 |
| Height H (mm): | 4,6 |
| Manufacturer's brand: | Optibelt |
| Minimum diameter: | 45 |
| Number of teeth (splines): | 5 |
| Product: | RBK |
| Profile: | PK |
| Spacing t (mm): | 3,56 |
| Width B (mm): | 17,8 |
| Číslo výrobce: | 1663141 |
| Značení: | 335-K |
| Řada: | 5 PK 850 |
| Typ: | víceklínový žebrový řemen |
