Multi-ribbed belt 5 PJ 711 (280-J) optibelt RB
Code: 245937
Product detailed description
Multi-V-belt 5 PJ 711 from the manufacturer optibelt, type RB. Also known as a grooved belt, toothed belt or ribbed belt. It meets high demands on power transmission and high speeds. The inch designation is 280-J, where \J\ stands for the profile - equivalent to \PJ\ and 280 is the inch length of the belt. In this case 28 inches = 711 mm. What is not indicated on the belt is the number of ribs. Because the belt is cut from the sleeve, the number of ribs (v-ribs) is required. 5 pieces of ribs. The belt has a very long service life and is suitable for small pulley diameters."""Additional parameters
| Category: | Belts > flat ribbed > PJ 2.34 mm > 5 PJ |
|---|---|
| Weight: | 0.032 kg |
| EAN: | 4014486119701 |
| Calculation length Lw, Lp, mm: | 711 |
| Height H (mm): | 3,5 |
| Manufacturer's brand: | Optibelt |
| Minimum diameter: | 20 |
| Number of teeth (splines): | 5 |
| Product: | RB |
| Profile: | PJ |
| Spacing t (mm): | 2,34 |
| Width B (mm): | 11,7 |
| Číslo výrobce: | 1769338 |
| Značení: | 280-J |
| Řada: | 5 PJ 711 |
| Typ: | víceklínový žebrový řemen |
