Multi-ribbed belt 4 PL 1333 (525-L) optibelt RB
Code: 251055
Product detailed description
Multi-V-belt 4 PL 1333 from the manufacturer optibelt, type RB. Also known as a grooved belt, toothed belt or ribbed belt. It meets high demands on power transmission and high speeds. The inch designation is 525-L, where \L\ stands for the profile - equivalent to \PL\ and 525 is the inch length of the belt. In this case 52.5 inches = 1333 mm. What is not indicated on the belt is the number of ribs. The number of ribs is 4 pieces. The belt has a very long service life and is suitable for small pulley diameters."""Additional parameters
| Category: | Belts > flat ribbed > PL 4.7 mm > 4 PL |
|---|---|
| Weight: | 0.219 kg |
| EAN: | 4014486116120 |
| Calculation length Lw, Lp, mm: | 1333 |
| Height H (mm): | 7 |
| Manufacturer's brand: | Optibelt |
| Minimum diameter: | 75 |
| Number of teeth (splines): | 4 |
| Product: | RB |
| Profile: | PL |
| Spacing t (mm): | 4,7 |
| Width B (mm): | 18,8 |
| Číslo výrobce: | 1847956 |
| Značení: | 525-L |
| Řada: | 4 PL 1333 |
| Typ: | víceklínový žebrový řemen |
