Lubline Trafo N - 10 L electrical insulating oil ( Mogul Trafo NA )

Product detailed description

Lubline TRAFO N Lubline TRAFO N is a high quality uninhibited electrical insulating oil, specially designed for use in transformers of all voltage levels. This product is made from a deeply refined base oil obtained from naphthenic petroleum, which gives it excellent electrical insulating properties and long service life. Lubline TRAFO N is an ideal choice for transformers, switches, contactors, power capacitors and other electrical equipment where reliable insulation and cooling function is required. oxidation stability

Technical parameters:

• Density: 868 kg/m? (ČSN EN ISO 12185)
• Viscosity at 40°C: 9.4 mm?/s Flash point: 155 °C (ČSN EN ISO 2592)
• Pour point: 51 °C (ČSN EN ISO 3016)
• Surface tension at 25°C: 47 mN/m (IEC 62961)
• Dielectric strength (IEC 60156)
• Acidity value: 0.005 mg KOH/g (ČSN ISO 6618)
• Dissipation factor tg ? at 90 °C: 0.001 (STN EN 60247)

Ab transformers of all voltage levels, including those with the highest voltage and power. It is also ideal for switches, contactors, power capacitors and other electrical equipment where reliable insulation and cooling function is required.

Standards and certifications: 1767.11999

Storage: The product should be stored in closed containers in ventilated areas at temperatures up to 40°C. The warehouse must be equipped with a first aid kit and a source of drinking water. It is important to prevent product spillage due to the risk of slipping.

Technical data sheet or safety data sheet Lubline TRAFO N on request.
