Loctite SI 5091 - 300 ml UV silicone adhesive

Product detailed description

Loctite SI 5091 (formerly known as Loctite 5091 - IDH: 135257) is a UV silicone adhesive designed for potting, coating and sealing a variety of automotive, electronic, military and industrial components. This single-component adhesive cures using UV and moisture, ensuring fast and efficient processing even in shaded areas. The product is highly flexible and self-leveling, which increases the load-bearing capacity of the joint and improves shock absorption. Its ability to withstand a wide temperature range ensures long-term durability in harsh environments.

Benefits:

• Fast curing using UV with secondary moisture curing.
• High flexibility, suitable for sealing and bonding. and most plastics.
• Self-leveling properties that allow for even filling of cavities.

Technical parameters:

• Technology: Silicone
• Chemical type: Acetoxy silicone
• Viscosity: 4,000 to 6,000 mPa·s
• Density: 1.01 g/cm?
• Temperature resistance: -60 °C to +150 °C
• Elongation at break: ? 75 %
• ?>li
• Shore hardness: 31 – 37 A
• Shear strength: (aluminum to glass) 0.01 to 0.1 N/mm?
• Dielectric strength: 18 kV/mm
• UV cure depth:
• ach: in shaded areas

Application: Loctite SI 5091 is suitable for automotive, electronic, military and industrial components where potting, coating or sealing is required. It is recommended for flexible applications requiring good adhesion to a variety of materials such as metals, glass or plastics. Once cured, it offers medium strength, high flexibility and the ability to withstand temperatures up to +150 °C. It is resistant to moisture and other chemical influences, making it suitable for harsh operating conditions. mW/cm? for curing.

• Surface preparation: For thorough degreasing and removal of dirt, use Loctite SF 7200 cleaner, which effectively breaks down the joint and material and effectively breaks down the joint.

  Product application: For precise and controlled application, use a standard application gun, such as Teroson Staku. This tool is designed for precise dosing and optimal handling of sealants and adhesives.

• Nozzles: One round nozzle is included in the package. If necessary, additional nozzles can be purchased, such as the Loctite nozzle for silicones, for a trouble-free workflow.

  easy selection of a suitable silicone adhesive



  Physical properties:

  • Coefficient of thermal expansion: 2.82×10?? K??
  • Water absorption: 0% after 24 hours
  • Shrink

    Instructions for use:

    1. Ensure that surfaces are clean and degreased.
    2. Apply the product to prepared surfaces and expose to UV radiation with a minimum intensity of 75 mW/cm? for 60 seconds.
    3. For shading. The depth of cure reaches up to 6 mm in 24 hours.
    4. Full mechanical properties are achieved after 72 hours.
    5. Excess material can be removed using non-polar solvents.



    Packaging:Storage: Store in unopened original containers in a dry place at temperatures recommended on the product label. Do not expose the product to excessive heat or cold.

    Technical data sheet or safety data sheet for Loctite SI 5091 on request.
