INA KH 16-PP bearing
Code: 399917
Product detailed description
INA KH 16-PP linear ball bearing
The INA KH 16-PP linear ball bearing is a compact and reliable solution for linear motion applications. This bearing is equipped with double-row raceways that enable smooth and precise movement with minimal friction. Thanks to its compact dimensions and low weight, it is ideal for installation in confined spaces.
Technical parameters:
- Moving speed: up to 3 m/s
- INA KH 16-basic model without any added 16-P -single seal version ("P" means seal), the seal is located on one side of the bearing.
- INA KH 16-PP -double seal version (both sides have seals).
- INA KH 16-PP-RROC - double seal version gasket (PP) RROC.
- N
INA KH 16-PP is an ideal choice for applications requiring precise and reliable linear movements, such as CNC machines,
/> The INA KH 16-PP bearing has several modifications
Additional parameters
| Category: | Bearings > linear technique > rod guides with bushings > ball bearings > compact KH > sealed on both sides |
|---|---|
| Weight: | 0.027 kg |
| EAN: | 4012802049893 |
| Diameter D (mm): | 16, 24 |
| Hole profile: | cylindrical |
| Length L (mm): | 30 |
| Manufacturer's brand: | INA |
| Material: | steel |
| Seal: | mutual |
| Width B (mm): | 16 |
| Číslo výrobce: | 000064807-0000 |
| Značení: | KH16-PP |
| Typ: | lineární kuličkové ložisko |
