INA K 10x13x10 TV needle cage

Code: 658573
Not rated
2,79 € –8 %
INA K 10x13x10 TV needle cage
2,79 € –8 % 2,55 € / pcs 3,08 € incl. VAT
In stock (9 pcs)
Delivery to:
06/08/2025
Delivery offer
INA needle roller bearing K10x13x10 TV, inner diameter 10 mm, outer diameter 13 mm, width 10 mm, polyamide cage, temperature range -20 to +120 °C.

Detailed information

Delivery throughout the EU

Product detailed description

INA K 10x13x10 TV needle roller bearing is a precisely designed component for applications where efficient power transmission is required in a minimum space. This product is part of the portfolio of the renowned manufacturer INA, which is known for its quality and reliability in the field of bearings and related components.

This needle roller bearing has an inner diameter of 10 mm, an outer diameter of 13 mm and a width of 10 mm. It is designed as a single-row cage, which means that it contains one row of needle rollers. These rollers are arranged to minimize friction and maximize load capacity in a limited space. The cage is made of polyamide, a material known for its wear resistance and low weight, with the total weight of the component being only 0.002 kg.

The temperature range for this needle cage is from -20 °C to +120 °C, which allows it to be used in various industrial conditions, including those where there are significant temperature fluctuations. The cylindrical hole profile ensures easy assembly and disassembly, which is advantageous for maintenance and replacement in mechanical applications.

This needle cage is ideal for use in applications where it is necessary to ensure high load capacity with minimal dimensions, such as gearboxes, clutches and other mechanisms where efficiency and reliability are key. Thanks to its design features and material composition, it is suitable for a wide range of industrial sectors.

Additional parameters

Category: Bearings > needle > cage > d = 10 mm > D = 13 mm
Weight: 0.002 kg
EAN: 4047643324502
Diameter D (mm): 10, 13
Hole profile: cylindrical
Manufacturer's brand: INA
Width B (mm): 10
Číslo výrobce: 000024090-6063
Značení: K10X13X10-TV/0-7
Typ: jehlová klec
