INA 3807-2Z angular contact ball bearing

Product detailed description

INA 3807-2Z is an angular contact ball bearing designed for applications requiring high precision and reliability. This bearing is manufactured by INA, a company known for its quality bearing solutions. The bearing has an inner diameter of 35 mm, an outer diameter of 47 mm and a width of 10 mm, making it suitable for various industrial applications where space constraints are critical.

The bearing is made of high-quality steel, which ensures a long service life and wear resistance. It is equipped with a polyamide cage, which reduces friction and allows smooth operation during operation. Both ends of the bearing are protected by sheet metal covers, which provide protection against contamination and ensure long-term operational reliability.

This bearing is designed as a double-row, which means that it can carry higher axial and radial loads compared to single-row bearings. The contact angle is not precisely specified, but is typically in the range of 30-40 degrees, allowing for the effective transmission of combined loads. The bearing operates in a temperature range of -20 °C to +120 °C, making it suitable for a wide range of operating conditions.

The running accuracy is in the P0/PN or ABEC 1 class, which is the standard accuracy for common applications. The bearing has normal radial clearance, which is suitable for most applications where special adjustments are not required. The total weight of the bearing is 0.04 kg, which contributes to its easy handling and installation.

The INA 3807-2Z is an ideal choice for applications where a combination of radial and axial loads is required, in a compact and efficient package. Its design without a flange or groove on the outer ring allows for easy integration into various mechanical systems.
