Flat set screw - hex DIN 913 M6x60 galvanized

Product detailed description

The set screw with a flat end and internal hexagon, manufactured according to DIN 913, ISO 4026 and ČSN 021187, is designed for precise adjustment and locking of parts without damaging the seating surface. This screw has a metric thread with a diameter of M6, while the total thread length is 60 mm. The thread pitch is 1.00 mm, which ensures reliable and precise adjustment.

The screw is made of steel with a strength class of 45H, which guarantees high resistance to mechanical stress. The surface treatment is made with white zinc plating, which provides increased protection against corrosion and extends the life of the component in difficult conditions.

The internal hexagon, also known as an inbus, allows for easy assembly and disassembly using a standard hexagonal wrench, which increases efficiency in assembly operations. The diameter of the internal hexagon is 4 mm and the head width is 3 mm, which is in accordance with the above standards.

This set screw is ideal for applications where precise adjustment and fixation of components without surface damage is required, such as in mechanical engineering, electrical engineering or when assembling fine mechanisms.
