Flat beveled washer DIN 125B M56 / 58.0 galvanized
Code: 850281
Product detailed description
Flat beveled washer DIN 125B M56 / 58.0 galvanizedAdditional parameters
| Category: | Fasteners > pads flat > hex chamfered DIN 125B, ISO 7090 > galvanized steel 100HV |
|---|---|
| Weight: | 0.383 kg |
| EAN: | 4043952047903 |
| CSN standard: | 021702 |
| Diameter D (mm): | M56 |
| Diameter d1 (mm): | 58 |
| Diameter D2 (mm): | 105 |
| DIN standard: | 125B |
| Hardness: | 100HV |
| Height H (mm): | 9 |
| ISO standard: | 7090 |
| Material: | steel |
| Surface finish: | zinc white |
