Ergo 3120 - 310 ml RTV silicone red (MEKO-free)

Product detailed description

Ergo 3120 Super RTV Silicone RED

Ergo 3120 Super RTV Silicone RED is a neutral curing, one-component silicone sealant designed for a wide range of industrial applications. Due to its low odor and non-corrosive properties, it is ideal for use in environments where high temperature resistance, mechanical strength and vibration resistance are required. This product provides excellent sealing, protection and adhesion to various materials, making it ideal for applications in the field of heating, cooling and protection of electronic components from external influences such as vibration, shock, moisture and chemicals.

Benefits:

• Paste, odor
• Neutral and acid-free curing (non-corrosive)
• Very high temperature resistance
• Excellent resistance to weathering and chemicals

Technical parameters:

• silicone
• Curing system: Moisture curing
• Appearance: Red, thixotropic paste
• Density at 20 °C: ~ 1.27 g/ml
• Viscosity at 25 °C (EN 12092, Conliplatesystem): 58'000 – 73'000 mPa•s

  - Shear rate 100 s-1: 15'000 – 25'000 mPa•s

• Extrusion speed at 25 °C with 5.5 bar and 3 mm orifice: 150 – 1 mm layer at 23 °C and 50 % rh: 5 – 10 minutes
• Curing process at 23 °C and 50 % rh after 24 h: 2 – 3 mm
• Volume shrinkage: 5 – 7 %
• Weight loss: 1 %

Application:

Ergo 3120 Super RTV Silicone RED is ideal for bonding and sealing parts in household appliances (e.g. ovens and ceramic hobs) boards), seals in electronic components (e.g. batteries) and seals in automotive applications (e.g. intake manifolds, oil pumps, oil pans, camshaft bearing caps, transmission covers, front covers, exhaust manifolds, exhaust flanges, engine covers and flanges). properties:

Use for application:

For optimal application of the product, it is recommended to use standard application guns for silicone sealants.

Instructions For use, surfaces must be clean, dry and free of grease.

2. Trim the tip of the cartridge and screw on the application nozzle.

3. Apply the sealant evenly to the desired area using the application gun.

4. If necessary, smooth the surface of the sealant within 5 minutes of application.

5. Allow to cure at room temperature.

Standards and certifications:

Packaging:

Available packaging options include cartridges, metal tubes and cans with varying shelf lives.

Storage:

Store at room temperature to maintain product properties. Shelf life is 12 months in cartridges and 24 months in metal tubes or cans.

Technical data sheet or safety data sheet for Ergo 3120 Super RTV Silicone RED on request.
