Double-sided V-belt HCC 5000 Lw CC 193" optibelt DK

Product detailed description

Optibelt DK is a special double-sided V-belt designed for power transmission in drives with reverse operation or external tensioning, where the belt contacts both sides. This belt is designed with an HCC profile, which has a width of 22 mm and a height of 17 mm. The calculated belt length is 5000 mm, with an inner length of 4980 mm and an outer length of 5045 mm. The minimum pulley diameter on which the belt can be mounted is 224 mm.

Thanks to the symmetrical design with a central tension member, it ensures even force distribution and high strength under bidirectional loads. The belt is made of a durable rubber compound and is equipped with a fabric covering that provides protection against abrasion, dust, oils and temperature fluctuations. This design allows the belt to run quietly and smoothly even under high loads and dynamic operating conditions.

Optibelt DK is used in technically demanding applications such as conveyors, return rollers, agricultural and forestry machinery, or industrial reversing drives. Thanks to its robustness, reliability and antistatic properties according to ISO 1813, it is also suitable for demanding operating environments with limited space and requirements for a long service life.
