Double-sided V-belt HCC 4300 Lw CC 165" optibelt DK

Product detailed description

Optibelt DK is a special double-sided V-belt, designed for power transmission in drives with reverse operation or external tensioning, where the belt contacts both sides. The HCC profile, sometimes also referred to as CC, gives a belt width of 22 mm, while the height is 17 mm. This belt is hexagonal (hexa), which allows it to be used in applications where double-sided engagement is required.

The number 4300 represents the calculated (center) length in millimeters, while the number 165 indicates the internal length in inches, which corresponds to 4280 mm. The outer length of the belt is 4345 mm. The belt is equipped with a central tension member, which ensures even force distribution and high strength under bidirectional loads.

Made of a durable rubber compound and provided with a fabric covering, the belt is protected against abrasion, dust, oil and temperature fluctuations. This design allows for quiet and smooth operation even under high loads and dynamic operating conditions. Optibelt DK is suitable for technically demanding applications such as conveyors, return rollers, agricultural and forestry machinery, or industrial drives with reverse operation.

Thanks to its robustness, reliability and antistatic properties according to ISO 1813, this belt is ideal for demanding operating environments with limited space and requirements for a long service life. The minimum diameter of the pulley on which the belt can be mounted is 224 mm. The product is manufactured by the renowned manufacturer Optibelt, which guarantees high quality and reliability in operation.
