Double-sided V-belt HCC 2500 Lw CC 94" optibelt DK

Product detailed description

Optibelt DK is a special double-sided V-belt designed for power transmission in drives with reverse operation or external tensioning, where the belt contacts both sides. Thanks to its symmetrical design with a centrally located tension member, it ensures even force distribution and high strength under bidirectional loads. The belt is made of a durable rubber compound and equipped with a textile covering that protects against abrasion, dust, oils and temperature fluctuations. The belt design allows for quiet and smooth operation even under high loads and dynamic operating conditions.

The HCC profile, sometimes also referred to as CC, determines the belt width, which is 22 mm, while the belt height is 17 mm. The calculated (central) length of the belt is 2500 mm, while the inner length is 2480 mm and the outer length reaches 2545 mm. The belt is designed for a minimum pulley diameter of 224 mm. It is manufactured by Optibelt under the trade name DK.

Optibelt DK is used in technically demanding applications such as conveyors, return rollers, agricultural and forestry machinery or industrial reversing drives. Thanks to its robustness, reliability and antistatic properties according to ISO 1813, it is also suitable for demanding operating environments with limited space and requirements for a long service life.
