Double-sided V-belt HBB 2370 Lw BB 90" optibelt DK

Product detailed description

Double-sided V-belt HBB 2370 Lw BB 90" optibelt DK is a specially designed component for power transmission in drives with reverse operation or external tensioning, where the belt contacts both sides. The HBB profile, also known as BB, indicates a belt width of 17 mm, while the belt height is 13 mm. The calculated (central) length of the belt is 2370 mm, while the inner length is 2345 mm and the outer length reaches 2395 mm. The minimum diameter of the pulley on which the belt can be mounted is 125 mm.

The belt is made of a durable rubber compound and equipped with a fabric covering that provides protection against abrasion, dust, oil and temperature fluctuations. The symmetrical design with a central tension member ensures even force distribution and high strength under double-sided loads. This design allows for quiet and quiet operation. operation even under high loads and dynamic operating conditions.

Optibelt DK is suitable for technically demanding applications such as conveyors, return rollers, agricultural and forestry machinery or industrial drives with reverse operation. Thanks to its robustness, reliability and antistatic properties according to ISO 1813, it is also ideal for demanding operating environments with limited space and requirements for a long service life. It is manufactured by the renowned company Optibelt, which is known for its quality products in the field of power transmission.
