Delimiting washer DIN 988 20x32x0.5
Code: 852599
Product detailed description
The shim according to DIN 988 with dimensions 20x32x0.5 mm is a structural component designed for precise adjustment of axial clearances in mechanical assemblies. This shim is made of hardened steel 2K50, which provides it with high strength and resistance to mechanical wear. The dimensions of the shim are defined by the inner diameter d1 of 20 mm, the outer diameter d2 of 32 mm and the thickness s of 0.5 mm.The shim is without surface treatment, which simplifies its integration into assemblies where additional corrosion protection is not required. It is ideal for applications where precise adjustment of bearings, shafts and gearboxes is required, while ensuring optimal functionality and long service life of mechanical systems. Thanks to its thin design, it allows fine tuning and alignment of components within mechanical assemblies.
Additional parameters
| Category: | Fasteners > pads flat > demarcation DIN 988 > hardened steel without PU > s = 0.50 mm |
|---|---|
| Weight: | 0.002 kg |
| EAN: | 4043952758755 |
| Diameter d1 (mm): | 20 |
| Diameter D2 (mm): | 32 |
| DIN standard: | 988 |
| Material: | hardened steel 2K50 |
| Surface finish: | without modification |
| Width s (mm): | 0,5 |
