Conical pin DIN 1B 6x32

Product detailed description

The DIN 1B 6x32 tapered pin is a precision connecting element manufactured according to the DIN 1B standard, which is equivalent to ISO 2339 B and ČSN 022153. This pin is turned with a cylindrical head and is intended for use in mechanical assemblies where there is a requirement for fixed and detachable connections with precise guidance.

The pin has a diameter of 6 mm and a length of 32 mm, which corresponds to its designation 6x32. It is made of free-cutting steel, which is known for its good machinability and suitability for mass production. The surface of the pin is not treated, which means that it is supplied in a raw state without additional surface treatments, such as electroplating or passivation.

The pin is structurally designed with rounded ends, which facilitates its assembly and disassembly in assemblies. The conical shape of the pin ensures self-locking in the connection, which means that after being inserted into the corresponding hole, the pin is firmly seated and resists axial forces. This type of pin is ideal for applications where it is necessary to ensure precise guidance and stability of components, while also allowing easy disassembly without damaging the assembly. Due to its properties, the DIN 1B 6x32 tapered pin is suitable for a wide range of industrial applications, including mechanical engineering, tool and equipment manufacturing, where it is necessary to ensure a reliable and precise mechanical connection.
